Water Bath For PVC Cable Testing With Digital Temp Control & Circulating Pump
  • nama
  • nama
  • nama
  • nama

Water Bath For PVC Cable Testing With Digital Temp Control & Circulating Pump

MOQ: 1
harga: dapat dinegosiasikan
Kemasan Standar: kasus kayu lapis
Periode pengiriman: 30 Hari
Cara Pembayaran: T/T
Kapasitas pasokan: 10 set per bulan
Rincian Informasi
Deskripsi Produk
Informasi detil
Tempat asal
Tiongkok
Nama merek
Sinuo
Sertifikasi
Calibration Certificate(Cost Additional)
Nomor model
SNQC1015(750L)
Dimensi batin:
1500×500×1000mm
Kisaran Suhu:
Suhu kamar ~ 100℃
Stabilitas suhu:
<1,5℃
Daya pemanas:
18kW
Kekuatan isolasi:
5kW
Sirkulasi suhu:
Pompa sirkulasi untuk suhu seragam
Menyoroti:

PVC cable water bath tester

,

digital temperature control water bath

,

circulating pump cable testing equipment

Deskripsi Produk
Water Bath For PVC Cable Testing With Digital Temp Control & Circulating Pump
This stainless steel water bath equipment features electric heating with intelligent temperature control and digital display. Designed for PVC cable testing, it ensures temperature uniformity through optional circulating pump functionality, making it ideal for constant temperature applications with water or oil.
Key Features
  • Stainless steel construction for durability and corrosion resistance
  • Precision digital temperature control with LCD display
  • Optional circulating pump for uniform temperature distribution
  • Insulation ports for cable threading during tests
  • Compliant with IEC 60811-402:2012 and IEC502-83 standards
  • Low water level alarm and automatic shut-off protection
  • Automatic water replenishment system
  • Computer interface (485) for data monitoring
Technical Specifications
Parameter Specification
Inner Dimensions (L×W×H) 1500 × 500 × 1000 mm
Temperature Control Range Room temperature to 100°C (user adjustable)
Temperature Stability <1.5°C
Electric Heating Power 18kW
Insulation Power 5kW
Input Voltage AC 380V/50HZ
Cover Hole Configuration 12 holes (2 each of 1, 2, 3, 4, 5, 10 cm)
Water Bath For PVC Cable Testing With Digital Temp Control & Circulating Pump 0
Usage Instructions
Before operation, carefully review the manual and verify instrument insulation using a megohmmeter. This equipment requires distilled water for operation - river water, hard water, or untreated tap water may cause scale buildup and affect performance. Regular cleaning is recommended when using tap water.
Note: This equipment is specifically designed for electrical performance testing of PVC plastic cables and is suitable for quality inspection agencies and wire/cable manufacturers.
